Thông tin chi tiết sản phẩm:
|
| OE Number: | W01-358-9466,1T15MT-6,1R12-365,64276/AS9466,135772,352-9466,SC2175,SC2175,364QS28,574QL411M,49048-000,49674-1&2 | Condition: | New |
|---|---|---|---|
| Type: | Truck Air Spring | gross weight: | 7.613 kg |
| net weight: | 7.073 kg | packing size: | 27*27*36 cm |
| Outer diameter: | φ255 | Maximum height: | 485mm |
| Minimum height: | 156mm | Piston material: | Plastic |
| Sealing configuration: | Crimp Cover Plate + Vulcanized Sealing Plate | ||
| Làm nổi bật: | 1V 9466 truck air spring,Firestone W01-358-9466 air spring,Goodyear 1R12-365 truck spring |
||
| Brand | Reference Numbers | Numbering Discrepancy |
|---|---|---|
| Firestone | W01-358-9466 | W013589466 / W01-3589466 / W01 358 9466 |
| Firestone | 1T15MT-6 | 1T15MT6 / 1T15MT-6 / 1T15 MT 6 |
| Goodyear | 1R12-365 | 1R12365 / 1R12 365 / :1R12365 |
| Goodyear | 173 | :173 |
| Goodyear | 197 | :197 |
| Contitech | 64276 | :64276 |
| Contitech | AS9466 | :AS9466 |
| Airtech | 135772 | :135772 |
| Airtech | 39466K | :39466K |
| Dayton | 352-9466 | 3529466 / 352 9466 / :3529466 |
| Loadguard | SC2175 | :SC2175 |
| Mack | 364QS28 | :364QS28 |
| Mack | 574QL411M | :574QL411M |
| Specifications | Parameters |
|---|---|
| Extended Height | 450mm |
| Compressed Height | 156mm |
| Top Plate Width | 231mm |
| Piston Width | 255mm |
| Weight | 7.613 kg |
| Package Dimensions | 27*27*36cm |
